Specifications
Model: EAST V6 200CC 250CC 400CC | ||||
Specifications/Features: | ||||
ENGINE TYPE | 150CC, CGB | 200CC CBB | 250CC CBB | 400CC WATER COOLING |
Displacement | 149.4ml | 196ml | 223ml | 367ml |
Engine | 1 Cylinder,4 stroke | 1 Cylinder,4 stroke | 1 Cylinder,4 stroke | Double Cylinder,6 speed |
Bore & Stroke | 62×49.5mm | 63.5*62.2 | 65.5*66.2 | 63.5mm×53mm |
Cooling System | Air Cooled | Air Cooled | Air Cooled | water cooled |
Compression Ratio | 9.2:1 | 9.0:1 | 9.25:1 | 9.2:1 |
Fuel feed | 90# | 90# | 90# | 92# |
Max Power( Kw/rpm) | 8.5/8000 | 9.8/7000 | 12/7500 | 18.6/8300 |
Max Torque(N.M/rpm) | 10/7500 | 15.5/5000 | 18/5500 | 25.5/6200 |
Max Speed | 90 km/h | 105km/h | 125 km/h | 170-180km/h |
Ground clearance | 210 mm | 210mm | 210mm | 210mm |
Fuel consumption | 2.2L/100KM | 2.3L/100KM | 2.4L/100KM | 2.6L/100KM |
Ignition | CDI | CDI | CDI | CDI |
Fuel tank capacity | 13L | 13L | 13L | 13L |
Starting System | Electric+kick start | Electric+kick start | Electric+kick start | Electric start |
Front Brakes | double Disc brake | double Disc brake | double Disc brake | double Disc brake |
Rear Brake | single Disc brake | single Disc brake | single Disc brake | single Disc brake |
Front suspension | Hydraulic Suspension | Hydraulic Suspension | Hydraulic Suspension | Hydraulic Suspension |
Rear suspension | Hydraulic Suspension | Hydraulic Suspension | Hydraulic Suspension | Hydraulic Suspension |
Front tires | 110/70-17 | 110/70-17 | 110/70-17 | 110/70-17 |
Rear tires | 140/70-17 | 140/70-17 | 140/70-17 | 140/70-17 |
Wheel Base | 1320 mm | 1320 mm | 1320 mm | 1320 mm |
Payload | 150kg | 150kg | 150kg | 150kg |
Net Weight | 136kg | 140kg | 140kg | 140kg |
Gross Weight | 161kg | 165kg | 165kg | 165kg |
Packing type | Steel + Carton | Steel + Carton | Steel + Carton | Steel + Carton |
L*W*H | 2080*740*1100 mm | 2080*740*1100 mm | 2080*740*1100 mm | 2080*740*1100 mm |
Packing size | 1950*570*860 mm | 1950*570*860 mm | 1950*570*860 mm | 1950*570*860 mm |
20' container (SKD) | 24 units | 24 units | 24 units | 24 units |
40' HQ container (SKD) | 72 units | 72 units | 72 units | 72 units |
20' container (CKD) | 44 units | 44 units | 44 units | 44 units |
40' HQ container (CKD) | 105 units | 105 units | 105 units | 105 units |
Product details
Company Advantages
· MOTOMAXXIS best racing motorbikes is fabricated adopting advanced production technology and smooth process.
· The product is in accordance with the international quality standards, so it is durable.
· WUXI EAST TECHNOLOGY CO. LTD has so far taken its place in the international best racing motorbikes market.
Company Features
· With excellent manufacturing ability, WUXI EAST TECHNOLOGY CO. LTD has created high-quality best racing motorbikes that makes itself stand out in the market.
· Our factory is strategically located. A great deal of thought has gone into the layout of our plant to create a common-sense flow of material arriving in our shipping area which continues throughout the manufacturing process until the finished part is prepared to ship to the customer.
· We energetically promote environmental protection and sustainable development. We will use cost-effective and mature technological production facilities to reduce environmental negative influence.
Application of the Product
The best racing motorbikes produced by WUXI EAST TECHNOLOGY is widely used in the industry.
Our solutions are specially set up to the customer's actual situation and needs to ensure that the solutions provided to the customer are effective.
WUXI EAST TECHNOLOGY CO. LTD
